[LS-5008PV5-EI-S-GL] H3C S5008PV5-EI-S

H3C S5008PV5-EI-S L2 Ethernet Switch
8*10/100/1000BASE-T Ports
2*1000BASE-X SFP Ports, (AC)
Switching capacity : 20Gbps
Packet forwarding rate : 15Mpps
Power consumption : MIN: 6W, MAX: 11W
Management port : 1 console port
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
VLAN : 802.1Q (up to 4K VLAN), Protocol-based, IP subnet based, MAC based, GUEST
Dimensions (W × D x H) : 266x160x43.6mm
Weight : ≤1.5kg

5 Years Warranty Basic 9x5 NBD-Ship Service

[LS-5016PV5-EI-S-GL] H3C S5016PV5-EI-S

H3C S5016PV5-EI-S L2 Ethernet Switch
16*10/100/1000BASE-T Ports
4*1000BASE-X SFP Ports, (AC)
Switching capacity : 40Gbps
Packet forwarding rate : 30Mpps
Power consumption : MIN: 7W, MAX: 16W
Management port : 1 console port
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
VLAN : 802.1Q (up to 4K VLAN), Protocol-based, IP subnet based, MAC based, GUEST
Dimensions (W × D x H) : 330x230x43.6mm
Weight : ≤2kg

5 Years Warranty Basic 9x5 NBD-Ship Service

[EWP-WA6520H-FIT] H3C Indoor WA6520H

H3C WA6520H-FIT Internal Antennas
4 Streams Dual Radio 802.11ax/ac/n Walljack Access Point, FIT
Ethernet ports Front panel :
4 x100/1000Mbps Ethernet ports
1 x USB port
Back panel :
1 x uplink GE port (100/1000Mbps)
1 x 10/100/1000M//2.5G optical port
Local Power supply : 54V DC
PoE : Port1: 802.3af
1 Console ports (RJ-45)
Built-in omni-directional antenna
3dBi antenna gain @2.4GHz
3dBi antenna gain @5GHz
Protection class : IP41
Overall power consumption : ≤15W (including USB）
Dimensions : 160mm×86mm×39mm
Weight : 0.35 kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[EWP-WA6520-FIT] H3C Indoor WA6520

H3C WA6520-FIT Internal Antennas
4 Streams Dual Radio 802.11ax/ac/n Access Point, FIT
Ethernet ports
1 x 100/1000M Rj45
1 x 10/100/1000M/2.5G optical port
Local Power supply : 54V DC
PoE : GE1: IEEE 802.3af, GE2 (SPF) : photoelectric composite power supply
1 Console ports (RJ-45)
Built-in omni-directional antenna
3dBi antenna gain @2.4GHz
4dBi antenna gain @5GHz
Protection class : IP41
Overall power consumption : ≤13W
Dimensions : 180mm×180mm×32mm
Weight : 0.5 kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[EWP-WA6320H-FIT] H3C Indoor WA6320H

H3C WA6320H-FIT Internal Antennas
4 Streams Dual Radio 802.11ax/ac/n Walljack Access Point, FIT
Ethernet ports Front panel :
4x100/1000Mbps Ethernet ports
1x RJ45 pass-through port
1x USB port
1x Console port
Back panel :
1x uplink GE port (100/1000Mbps)
1 x RJ45 pass-through port
Local Power supply : 54V DC
PoE : 802.3af
1 Console ports (RJ-45)
Built-in omni-directional antenna
3dBi antenna gain @2.4GHz
3dBi antenna gain @5GHz
Protection class : IP31
Overall power consumption : ≤12.95W
Dimensions : 160mm×86mm×30mm
Weight : 0.25 Kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[EWP-WA6320-FIT] H3C Indoor WA6320

H3C WA6320-FIT Internal Antennas
4 Streams Dual Radio 802.11ax/ac/n Access Point, FIT
Ethernet ports : 1*100/1000M RJ45
Local Power supply : 54V DC
PoE : 802.3af
1 Console ports (RJ-45)
Built-in omni-directional antenna
3dBi antenna gain @2.4GHz
5dBi antenna gain @5GHz
Protection class : IP41
Overall power consumption : ≤12.42W
Dimensions : 185mm×185mm×43mm
Weight : 0.4 Kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5008PV5-EI-HPWR-GL] H3C S5008PV5-EI-HPWR

H3C S5008PV5-EI-HPWR L2 Ethernet Switch
8*10/100/1000BASE-T PoE+ Ports (AC 125W)
2*1000BASE-X SFP Ports, (AC)
Switching capacity : 20Gbps
Packet forwarding rate : 15Mpps
Power consumption : MIN: 14W, MAX: 156W
Management port : 1 console port
VLAN : 802.1Q (up to 4K VLAN), Protocol-based, IP subnet based, MAC based, GUEST
Dimensions (W × D x H) : 330×230×43.6mm
Weight : ≤3kg

5 Years Warranty Basic 9x5 NBD-Ship Service

[RT-MSR830-6EI-GL] H3C MSR830-6EI

H3C MSR830-6EI-GL Router
6-Port Gigabit Router (2GE WAN, 4GE LAN/WAN)
Forwarding Performance : 200 Mbps
CPU : 800MHz
Memory : 1 GB
Flash : 256 MB
LAN port : 4 × GE ports (can be configured as WAN interfaces)
1 Console ports
1 CON ports
2 × GE copper ports
Dimensions (H×W×D) : 44 × 440 × 225 mm

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5024PV5-EI-GL] H3C S5024PV5-EI

H3C S5024PV5-EI L2 Ethernet Switch
24*10/100/1000BASE-T Ports
4*1000BASE-X Ports,(AC)
Switching capacity : 56Gbps
Packet forwarding rate : 42Mpps
Power consumption : MIN: 9W, MAX: 23W
Management port : 1 console port
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
VLAN : 802.1Q (up to 4K VLAN), Protocol-based, IP subnet based, MAC based, GUEST
Dimensions (W × D x H) : 440×160×43.6mm
Weight : ≤2.5kg

5 Years Warranty Basic 9x5 NBD-Ship Service

[RT-MSR810-EI] H3C MSR810-EI

H3C MSR810-EI Enterprise Ethernet Router
6-Port Gigabit Ethernet Router (2GE WAN (1GE+1SFP), 4GE LAN/WAN)
Forwarding Performance : 200Mpps
Memory : 1 GB
Flash : 256MB
CPU : 800MHz
LAN port : 4 × GE ports (can be configured as WAN interfaces)
1 USB ports
1 Console ports
1 × GE copper port
1 × SFP port
Dimensions (H × W × D) : 44 × 210 × 130 mm

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5130S-10P-EI-GL] H3C S5130S-10P-EI

H3C S5130S-10P-EI-GL L2 Ethernet Switch
8*10/100/1000Base-T Ports
2*1000Base-X SFP Ports,(AC)
Switching capacity : 20Gbps
Forwarding Capacity : 15Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC: 7W, MAX: AC: 12W
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC : Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 266×161×43.6 mm
Weight : ≤1.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[EWP-WX1804H-PWR] H3C Controller WX1804H

H3C WX1804H-PWR
5-Port 1000BASE-T Access Controller
Wireless throughput : 500Mbps
Port
- WAN 1*GE +
- LAN 4*GE(PoE+)
- 1*USB
Power supplies : 100V AC~240V AC:50/60Hz
MTBF : ≥38 years
Dimensions (WxDxH) : 220mm x 145.5mm x 27mm
Weight : 1.45 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5130S-12TP-EI-GL] H3C S5130S-12TP-EI

H3C S5130S-12TP-EI-GL L2 Ethernet Switch
8*10/100/1000BASE-T Ports, 2*GE Combo Ports
4*1000BASE-X SFP Ports,(AC)
Switching capacity : 24Gbps
Forwarding Capacity : 18Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC: 8W, MAX: AC: 14W
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 266×161×43.6 mm
Weight : ≤1.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[RT-MSR830-10EI-GL] H3C MSR830-10EI

H3C MSR830-10EI-GL Router
10-Port Gigabit Router (4GE WAN, 6GE LAN/WAN)
Forwarding Performance : 200 Mbps
CPU : 800MHz
Memory : 1 GB
Flash : 256 MB
LAN port : 6 × GE ports (can be configured as WAN interfaces)
1 USB ports
1 Console ports
1 CON ports
4 × GE copper ports
Dimensions (H×W×D) : 44 × 440 × 225 mm

1 Year Warranty Basic 9x5 NBD-Ship Service

[EWP-WA6526-FIT] H3C Indoor WA6526

H3C WA6526-FIT Internal Antennas
6 Streams Dual Radio 802.11ax/ac/n Access Point, FIT
Ethernet ports :
Port 1: 100/1000M/2.5G, RJ-45
Port 2: 100/1000M, RJ-45
Local Power supply : 54V DC
PoE : 2.5GE: IEEE 802.3at/af
1 Console ports (RJ-45)
1 USB port
Built-in omni-directional antenna
Protection class : IP42
Overall power consumption : ≤17.6W (include USB), ≤15.1W (without USB）
Dimensions (H × W × D) : 35 × 185 × 155 mm
Weight : 1.05 kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[RT-MSR830-6HI-GL] H3C MSR830-6HI

H3C MSR830-6HI-GL Router
6-Port Gigabit Router (2GE WAN (1Combo), 4GE LAN/WAN)
Forwarding Performance : 800Mbps
CPU : 1.3GHz
Memory : 1 GB
Flash : 256 MB/32GB
External Flash : Micro SD card
LAN port : 4 × GE ports (can be configured as WAN interfaces)
1 USB port
1 Console ports
1 CON ports
1 × GE copper ports
1 × GE combo port
Dimensions (H×W×D) : 44 × 440 × 225 mm

1 Year Warranty Basic 9x5 NBD-Ship Service

[EWP-WA6622-FIT] H3C Indoor WA6622

H3C WA6622-FIT Internal Antennas
6 Streams Dual Radio 802.11ax/ac/n Access Point, FIT
Ethernet ports
Port 1: 100M/1000M/2.5G/5G, RJ-45
Port 2: 100/1000M, RJ-45, IoT
Local Power supply : 54V DC
PoE : Port 1: 802.3at/af
1 Console ports (RJ-45)
1 USB port
Built-in omni-directional antenna
5dBi antenna [email protected]
5dBi antenna gain @5GHz
IoT Extension : BLE, RFID, ZigBee, etc.
Protection class : IP42
Overall power consumption : < 25W (excluding IoT modules and USB)
Dimensions (H × W × D) : 43 × 210 × 210 mm
Weight : 0.94 kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[RT-MSR810-LMS-EA] H3C MSR810-LMS

H3C MSR810-LMS-EA Enterprise Router
4G LTE Router(Mini),EMEA & APAC Edition
Memory : 1 GB DDR3
Flash : 256MB
FE port : 4 ports
1 USB ports
1 Console ports
2 LTE antenna port
Input voltage : 100 VAC to 240 VAC @ 50/60 Hz
Power rating : 10 W
Dimensions (H × W × D) : 35 × 115 × 100 mm

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5024FV3-EI-GL] H3C S5024FV3-EI

H3C S5024FV3-EI L2 Ethernet Switch
24*100/1000Base-X Ports
2*10/100/1000Base-T Combo Ports
4*1000Base-X Ports, (AC)
Switching capacity : 56Gbps
Packet forwarding rate : 78Mpps
Power consumption : ≤37W
Management port : 1 console port
VLAN : 802.1Q (up to 4K VLAN), Protocol-based, IP subnet based, MAC based, GUEST
Dimensions (W × D x H) : 440x260x43.6mm
Weight : <3kg

5 Years Warranty Basic 9x5 NBD-Ship Service

[EWP-WA6330-FIT] H3C Indoor WA6330

H3C WA6330-FIT Internal Antennas
6 Streams Triple Radio 802.11ax/ac wave2/ac/n Access Point, FIT
Ethernet ports : 2 (1*100/1000M/2.5G RJ45, 1*100/1000M RJ45 support IoT) support LACP
Local Power supply : 54V DC
PoE : Port1 : 2.5GE:802.3at/802.3af, Port2 : GE:PSE,802.3af
1 Console ports (RJ-45)
Built-in omni-directional antenna
Radio 1 : 5dBi antenna gain @ 5G
Radio 2 : 5dBi antenna gain @ 5G
Radio 3 : 5dBi antenna gain @ 2.4G or 5dBi antenna gain @ 5G
IoT Extension : Support BLE, RFID, ZigBee, etc.
Protection class : IP42
Overall power consumption : ≤ 34W (excluding IoT modules)
Dimensions : 210mm×210mm×45mm
Weight : 0.94 Kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[RT-MSR1104S-W] H3C MSR1104S-W

H3C MSR1104S-W Router
1GE+1SFP WAN, 4GE LAN/WAN, Dual-Radio Wi-Fi 6
Forwarding Performance : 1 Gbps
Memory : 1 GB
Flash : 256 MB
LAN port : 4 × GE copper ports
1 USB 2.0 port
1 Console ports
1 × GE copper port
1 × GE fiber port
Dimensions (H×W×D) : 43.6 × 266 × 161 mm

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5130S-10P-HPWR-EI-GL] H3C S5130S-10P-HPWR-EI

H3C S5130S-10P-HPWR-EI-GL L2 Ethernet Switch
8*10/100/1000BASE-T PoE+ Ports(AC 125W)
2*1000BASE-X SFP Ports,(AC)
Switching capacity : 20Gbps
Forwarding Capacity : 15Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN : AC: 13W, MAX : AC : 153W (PoE 125W）
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC : Rated voltage range : 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 330×230×43.6 mm
Weight : ≤2.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[RT-MSR830-10HI-GL] H3C MSR830-10HI

H3C MSR830-10HI-GL Router
10-Port Gigabit Router (4GE WAN (1Combo), 6GE LAN/WAN)
Forwarding Performance : 800Mbps
CPU : 1.3GHz
Memory : 1 GB
Flash : 256 MB/32GB
External Flash : Micro SD card
LAN port : 6 × GE ports (can be configured as WAN interfaces)
1 USB ports
1 Console ports
1 CON ports
3 × GE copper ports
1 × GE combo port
Dimensions (H×W×D) : 44 × 440 × 225 mm

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5130S-12TP-HPWR-EI-GL] H3C S5130S-12TP-HPWR-EI

H3C S5130S-12TP-HPWR-EI-GL L2 Ethernet Switch
8*10/100/1000BASE-T PoE+ Ports(AC 125W), 2*GE Combo Ports
4*1000BASE-X SFP Ports, (AC)
Switching capacity : 24Gbps
Forwarding Capacity : 18Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN:AC: 14W, MAX:AC: 156W (PoE 125W）
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 330×230×43.6 mm
Weight : ≤3kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-20P-EI-GL] H3C S5130S-20P-EI

H3C S5130S-20P-EI-GL L2 Ethernet Switch
16*10/100/1000BASE-T Ports
4*1000BASE-X SFP Ports,(AC)
Switching capacity : 40Gbps
Forwarding Capacity : 30Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC: 9W, MAX: AC: 19W
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 330×230×43.6 mm
Weight : ≤2kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[EWP-WA6528i-FIT] H3C Indoor WA6528i

H3C WA6528i-FIT Internal Antennas
8 Streams Dual Radio 802.11ax/ac/n Access Point, FIT
Ethernet ports :
1×100/1000M/2.5G/5G RJ-45
1×10/100/1000M RJ-45, Support IoT extension and Power out support LACP (support between both network ports for redundancy and increased capacity)
1×USB port
Local Power supply : 54V DC
PoE : 5GE: IEEE 802.3bt/at/af, 1GE: IEEE 802.3af, PSE
1 Console ports (RJ-45)
Built-in omni-directional antenna
External IoT Module : RFID/Zigbee
Protection class : IP42
Overall power consumption : ≤ 25W (excluding IoT modules)
Dimensions : 225mm x 225mm x 40mm
Weight : 1.05 kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[EWP-WA6620X-FIT] H3C Outdoor WA6620X

H3C WA6620X-FIT Integrated Internal and External Antennas
4 Streams Dual Radio 802.11ax/ac/n Industrial Access Point, FIT
Fixed port
- 2×100M/1000M Ethernet port, one support IoT extension & PSE ,802.3af
- Network ports support link aggregation (LACP) for redundancy and increased capacity
- 1xSFP
- 1×Console port (RJ45)
Power Source
- PoE Injector+55V DC Adapter (Optional)
- Adapted to 47~57V DC
Power consumption
- ≤31W (including PSE)
- ≤16W (excluding PSE)
Protection degree : IP68
Dimensions (H×W×D) : 250mm x 250mm x 79.5mm
Weight : 1.8 kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-28P-EI-GL] H3C S5130S-28P-EI

H3C S5130S-28P-EI-GL L2 Ethernet Switch
24*10/100/1000BASE-T Ports
4*1000BASE-X Ports,(AC)
Switching capacity : 56Gbps
Forwarding Capacity : 42Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC:9W MAX: AC:23W
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440×160×43.6 mm
Weight : ≤2.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5048PV5-EI-GL] H3C S5048PV5-EI

H3C S5048PV5-EI L2 Ethernet Switch
48*10/100/1000BASE-T Ports
4*1000BASE-X Ports, (AC)
Switching capacity : 104Gbps
Packet forwarding rate : 78Mpps
Power consumption : MIN: 18W, MAX: 41W
Management port : 1 console port
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
VLAN : 802.1Q (up to 4K VLAN), Protocol-based, IP subnet based, MAC based, GUEST
Dimensions (W × D x H) : 440×230×43.6 mm
Weight : ≤3.5kg

5 Years Warranty Basic 9x5 NBD-Ship Service

[EWP-WA7539-FIT] H3C WA7539 Indoor

H3C WA7539 Wi-Fi 7 Internal Antennas
12 Streams Triple Radio 802.11be/ax/ac/n Access Point (1*GE+1*10GE+1*10G PSFP), FIT
Interface :
1 x 10/100/1000M/2.5G/5G/10G Multigigabit Ethernet, RJ-45, PoE input
1 x 1000M/10G optical port, SFP+, PoE input
1 x 10/100/1000M Ethernet, RJ-45, PoE output
Local Power supply : 54V DC
PoE input :
1 x 10/100/1000M/2.5G/5G/10G Multigigabit Ethernet, 802.3bt/at
1 x 1000M/10G optical port, 802.3bt/at
PoE output : 1 x 10/100/1000M Ethernet, 802.3af
USB port : 1(2.0) at 2.5W
Console port : 1 × Management console port (RJ-45)
Built-in omni-directional antenna
Protection class : IP42
Dimensions : 225 mm × 225 mm × 47.2 mm
Weight : 1.4 kg

1 Years Warranty

[LS-5024PV5-EI-HPWR-GL] H3C S5024PV5-EI-HPWR

H3C S5024PV5-EI-HPWR L2 Ethernet Switch
24*10/100/1000BASE-T PoE+ Ports (AC 370W)
4*1000BASE-X SFP Ports, (AC)
Switching capacity : 56Gbps
Packet forwarding rate : 42Mpps
Power consumption : MIN: 19W, MAX: 448W
Management port : 1 console port
VLAN : 802.1Q (up to 4K VLAN), Protocol-based, IP subnet based, MAC based, GUEST
Dimensions (W × D x H) : 440×260×43.6mm
Weight : ≤6kg

5 Years Warranty Basic 9x5 NBD-Ship Service

[EWP-WA6636-FIT] H3C Indoor WA6636

H3C WA6636-FIT Internal Antennas
10 Streams Triple Radio 802.11ax/ac/n Access Point, FIT
Ethernet ports
1 x 100/1000M/2.5G/5G/10G Rj45
1 x 10/100/1000M Rj45 support IoT extension and Power out
1 x 10/100/1000M Rj45
support LACP (support between both network ports for redundancy and increased capacity)
1 x USB interface
PoE
10GE: IEEE 802.3bt/at
GE1: IEEE 802.3at/af
Both ethernets ports support PoE and they can work simultaneously
GE2: IEEE 802.3af, PSE
1 Console ports (RJ-45)
External IoT Module : RFID/Zigbee
Built-in omni-directional antenna
Protection class : IP42
Overall power consumption : ≤22.5W (excluding IoT modules)
Dimensions : 225mm X 225mm X 46mm
Weight : 1.05 Kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-28TP-EI-GL] H3C S5130S-28TP-EI

H3C S5130S-28TP-EI-GL L2 Ethernet Switch
24*10/100/1000Base-T Ports
2*GE Combo Ports
2*100/1000Base-X SFP Combo Ports
2*1000Base-X SFP Ports, (AC)
Switching capacity : 56Gbps
Forwarding Capacity : 42Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC:10W, MAX: AC:24W
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440×160×43.6 mm
Weight : ≤ 2kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[RT-MSR1008] H3C MSR1008

H3C MSR1008 Router
2*10GE (SFP+), 2*GE (Combo), 8*GE (RJ45)
Forwarding Performance : 4 Gbps
Memory : 2 GB
Flash : 4 GB
LAN port : 8 × GE copper ports (Four of them can be switched to routing mode.)
1 USB 2.0 port
1 Console ports
2 × 10GE SFP+ ports
2 × GE combo interfaces
Dimensions (H×W×D) : 43.6 × 266 × 161 mm

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-IE4300-12P-AC] H3C IE4300-12P-AC

H3C IE4300-12P-AC L2 Industrial Ethernet Switch
8*10/100/1000 BASE-T Ethernet ports
4*1000 BASE-X SFP optical ports
Switching capacity : 24Gbps
Forwarding capacity : 17Mpps
Input voltage : Rated voltage range: 100 to 240 VAC @ 50 or 60 Hz, Max voltage range: 85 to 264 VAC @ 45 to 65 Hz
Power consumption : MIN: 7W, MAX: 12W
VLAN Port-based, MAC-based, Protocol-based, Voice, Guest, QinQ and Selective QinQ, VLAN Mapping
Dimensions : 149*129.8*44mm
Weight : ≤1kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5130S-20P-PWR-EI-GL] H3C S5130S-20P-PWR-EI

H3C S5130S-20P-PWR-EI-GL L2 Ethernet Switch
16*10/100/1000BASE-T PoE+ Ports (AC 185W)
4*1000BASE-X SFP Ports, (AC)
Switching capacity : 40Gbps
Forwarding Capacity : 30Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC: 18W, MAX: AC: 223W (PoE 170W)
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 330×230×43.6 mm
Weight : ≤3kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-28S-LI-GL] H3C S5130S-28S-LI

H3C S5130S-28S-LI L2 Ethernet Switch
24*10/100/1000Base-T Ports
4*1G/10G Base-X SFP Plus Ports, (AC)
Port switching capacity : 128Gbps
Packet forwarding rate : 96Mpps
Input voltage range : 100 VAC to 240 VAC @ 50 Hz/60 Hz
Power consumption : MIN AC: 10W, MAX AC: 24W
Console ports : 1
VLAN : Port-based, QinQ, MAC, Voice
Dimensions (W × D x H) : 43.6×440×160 mm
Weight : <2.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5560S-28P-SI-GL] H3C S5560S-28P-SI

H3C S5560S-28P-SI-GL L3 Ethernet Switch
24*10/100/1000Base-T Ports
4*1000Base-X SFP Ports, (AC)
Switching capacity : 56Gbps
Forwarding Capacity : 42Mpps
Flash/SDRAM : 512MB/256MB
CPU : 1 Core, 800MHz
Input voltage : AC: The rated voltage range is 100V to 240V, 50/60Hz.
Power consumption : MIN: AC 9W, MAX: AC 23W
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice, MVRP
Dimensions (W × D x H) : 43.6 × 440 × 160 mm
Weight : ≤ 2.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[EWP-WX2812X-PWR] H3C Controller WX2812X

H3C WX2812X-PWR
16-Port (14*1000BASE-T and 2*SFP Plus) Access Controller
Wireless throughput : 4Gbps
Port
- LAN：2*SFP Plus + 12*PoE+
- WAN：2 GE
- 1*USB
Power supplies : 100V AC~240V AC:50/60Hz
Dimensions (WxDxH) : 220x147x28 mm
Weight : 0.9 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5130S-16S-PWR-EI] H3C S5130S-16S-PWR-EI

H3C S5130S-16S-PWR-EI L2 Ethernet Switch
12*10/100/1000Base-T PoE+ Ports
2*10/100/1000Base-T Ports
2*1G/10GBase-X SFP Plus Ports,(AC)
Switching capacity : 68Gbps
Forwarding Capacity : 51Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC: 14W, MAX: AC: 157W (PoE 125W）
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 300*260*43.6mm
Weight : ≤ 2.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[EWP-WA6628-FIT] H3C Indoor WA6628

H3C WA6628-FIT Internal Antennas
12 Streams Dual Radio 802.11ax/ac/n Access Point, FIT
Ethernet ports
Port 1: 100/1000M/2.5G/5G/10G, RJ-45
Port 2: 100/1000M, RJ-45
Local Power supply : 54V DC
PoE+
Port 1: 802.3bt/at
Port 2: 802.3at
Both ethernet ports support PoE and they can work simultaneously
1 Console ports (RJ-45)
1 USB port
Built-in omni-directional antenna
3dBi antenna gain @2.4GHz
4dBi antenna gain @5GHz
Protection class : IP42
Overall power consumption : < 30 W (excluding IoT modules and USB)
Dimensions (H × W × D) : 52 × 239 × 236 mm
Weight : 1.28 kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[EWP-WA6638-FIT] H3C Indoor WA6638

H3C WA6638-FIT Internal Antennas
12 Streams Triple Radio 802.11ax/ac/n Access Point, FIT
Ethernet ports
Port 1: 100/1000M/2.5G/5G/10G, RJ-45
Port 2: 100/1000M, RJ-45
PoE+ : Port 1: 802.3bt/at
Local power supply : 54V DC
1 Console ports (RJ-45)
1 USB port
Built-in omni-directional antenna
3dBi antenna gain @2.4GHz
4dBi antenna gain @5GHz
4dBi antenna gain @5GHz
IoT Extension : BLE, RFID, ZigBee, etc.
Protection class : IP42
Overall power consumption : < 30 W (excluding IoT modules and USB)
Dimensions (H × W × D) : 52 × 239 × 236 mm
Weight : 1.28 kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-IE4300-12P-PWR] H3C IE4300-12P-PWR

H3C IE4300-12P-PWR L2 Industrial Ethernet Switch
8*10/100/1000Base-T PoE+ Ports
4*1000BASE-X SFP Ports (8GE (PoE+)+4SFP, Dual DC)
Switching capacity : 24Gbps
Forwarding capacity : 17Mpps
Input voltage : Rated DC voltage: 54 - 57V, Max DC voltage: 48 – 57V
Power consumption : MIN: Single DC：11W Dual DC :14W, MAX: Single DC：141W Dual DC：144W
VLAN Port-based, MAC-based, Protocol-based, Voice, Guest, QinQ and Selective QinQ, VLAN Mapping
POE Single DC : 125W, Dual DC : 125W
Dimensions (W × D × H) 149*129.8*44mm
Weight : ≤1kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[RT-MSR810-LM-GL] H3C MSR810-LM

H3C MSR810-LM-GL Router
6-Port Gigabit 4G LTE Router (1GE,1SFP WAN,4GE LAN/WAN,4G LTE)
Memory : 1 GB DDR3
Flash : 256MB
LAN port : 4 × GE ports
1 USB ports
1 Console ports
1 × GE WAN port
1 × GE SFP port
Input voltage : 100 VAC to 240 VAC @ 50 to 60Hz
Max. input power : 24 W
Dimensions (H × W × D) : 43.6 × 266 × 161 mm

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5130S-28P-PWR-EI-GL] H3C S5130S-28P-PWR-EI

H3C S5130S-28P-PWR-EI-GL L2 Ethernet Switch
24*10/100/1000BASE-T PoE+ Ports(AC 185W)
4*1000BASE-X Ports,(AC)
Switching capacity : 56Gbps
Forwarding Capacity : 42Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC: 19W, MAX: AC: 230W (PoE 170W)
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440×260×43.6 mm
Weight : ≤4kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[RT-MSR1104S-W-CAT6] H3C MSR1104S-W-CAT6

H3C MSR1104S-W-CAT6 Router
1GE+1SFP WAN, 4GE LAN/WAN, Dual-Radio WiFi 6, 4G LTE CAT6
Forwarding Performance : 1 Gbps
Memory : 1 GB
Flash : 256 MB
LAN port : 4 × GE copper ports
1 USB 2.0 port
1 Console ports
1 × GE copper port
1 × GE fiber port
Dimensions (H×W×D) : 43.6 × 266 × 161 mm

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5130S-10MS-UPWR-EI-GL] H3C S5130S-10MS-UPWR-EI

H3C S5130S-10MS-UPWR-EI-GL L2 Ethernet Switch
8*1G/2.5GBase-T(UPoE) Ports
2*1G/10GBase-X SFP Plus Ports,(AC/DC)
Switching capacity : 80Gbps
Forwarding Capacity : 60Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : Min:AC:22.2 DC:17.38, MAX:AC:447 (PoE 370) DC:794.2 (PoE 740)
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz DC: Rated voltage range -54V～-57V DC
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 300*260*43.6mm
Weight : ≤3.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-28P-HPWR-EI-GL] H3C S5130S-28P-HPWR-EI

H3C S5130S-28P-HPWR-EI-GL L2 Ethernet Switch
24*10/100/1000BASE-T PoE+ Ports (AC 370W, DC 740W)
4*100/1000BASE-X Ports
4*GE Combo Ports, (AC/DC)
Switching capacity : 56Gbps
Forwarding Capacity : 42Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC: 23W DC:16W, MAX: AC: 446W (PoE 370W) DC:790W (PoE 740W)
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz DC: Rated voltage range - 54V～-57V DC
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440×260×43.6 mm
Weight : ≤ 4.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-28ST-EI-GL] H3C S5130S-28ST-EI

H3C S5130S-28ST-EI-GL L2 Ethernet Switch
24*10/100/1000Base-T Ports
2*10G BASEX SFP+ Ports
2*1/2.5/5/10G BASE-T Ports, (AC)
Switching capacity : 128Gbps
Forwarding Capacity : 96Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC:14.5W, MAX: AC:33W
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440*160*43.6 mm
Weight : ≤ 2.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[RT-MSR810-W-LM-GL] H3C MSR810-W-LM

H3C MSR810-W-LM-GL Router
6-Port Gigabit 4G LTE Wireless Router (1GE,1SFP WAN,4GE LAN/WAN,4G LTE,802.11n WiFi)
Memory : 1 GB DDR3
Flash : 256MB
LAN port : 4 GE ports
1 USB ports
1 Console ports
1 GE WAN port
1 GE SFP port
Input voltage : 100 VAC to 240 VAC @50/60 Hz
Power rating : 24 W
Dimensions (H × W × D) : 43.6 × 266 × 161 mm

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5170-28S-EI-GL] H3C S5170-28S-EI

H3C S5170-28S-EI-GL L2 Ethernet Switch
24*10/100/1000BASE-T Ports
4*1G/10G BASE-X SFP Plus Ports, (AC)
Switching capacity : 128Gbps
Forwarding Capacity : 96Mpps
Flash/SDRAM : 512M/1G
CPU : 1GHz, 2Cores
Latency (64byte/µs) : GE: < 5µs, 10GE < 3µs
Input voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz, Max voltage range: 90V~ 264V AC, 47~63HZ
Power consumption : 37W
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice VLAN/Private VLAN/Super VLAN, GVRP, Dynamic, Hardware-based switching, Guest
Dimensions (W × D x H) : 440mm×160mm ×43.6mm
Weight : ≤ 2.2kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-28S-EI-GL] H3C S5130S-28S-EI

H3C S5130S-28S-EI-GL L2 Ethernet Switch
24*10/100/1000BASE-T Ports
4*1G/10G BASE-X SFP Plus Ports,(AC)
Switching capacity : 128Gbps
Forwarding Capacity : 96Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC:10W, MAX: AC:24W
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440×160×43.6 mm
Weight : ≤2.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5048PV5-EI-PWR-GL] H3C S5048PV5-EI-PWR

H3C S5048PV5-EI-PWR L2 Ethernet Switch
48*10/100/1000BASE-T PoE+ Ports (AC 370W)
4*1000BASE-X SFP Ports, (AC)
Switching capacity : 104Gbps
Packet forwarding rate : 78Mpps
Power consumption : MIN: 36W, MAX: 467W
Management port : 1 console port
VLAN : 802.1Q (up to 4K VLAN), Protocol-based, IP subnet based, MAC based, GUEST
Dimensions (W × D x H) : 440×400×43.6mm
Weight : ≤6kg

5 Years Warranty Basic 9x5 NBD-Ship Service

[EWP-WX2860X] H3C Controller WX2860X

H3C WX2860X Access Controller
10*1000BASE-T Ports
2*SFP Plus Ports
Wireless throughput : 10Gbps
Port
- WAN 2 x 2.5GE
- LAN 8 x GE
- LAN 2 x SFP+
- 1 x USB
- 1 x Console
Power supplies : Built in single power supply
MTBF : ≥145 yrs
Dimensions (WxDxH) : 440 mm *250 mm *43.6 mm
Weight : 3.1 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[EWP-WA6528X-E-FIT] H3C Outdoor WA6528X-E

H3C WA6528X-E-FIT External Antennas
8 Streams Dual Radio 802.11ax/ac/n Industrial Access Point, FIT
Ethernet ports
1x100M/1000M/2.5G/5G Ethernet port
2x100/1000M/10G SFP+
1×Console port (RJ45)
Power Source
- 5GE 802.3bt/at/af
- POE injector
- Local Power Supply (100-264V AC)
Power consumption
- AC powered: ≤43W (100-264V)
- POE powered: ≤43W (802.3bt)
Protection degree : IP68
Dimensions : 280 mm (W) x 280 mm (D) x 85 mm (H)
Weight : 3.2 kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-52P-EI-GL] H3C S5130S-52P-EI

H3C S5130S-52P-EI-GL L2 Ethernet Switch
48*10/100/1000BASE-T Ports
4*1000BASE-X SFP Ports, (AC)
Switching capacity : 104Gbps
Forwarding Capacity : 78Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC:18W, MAX: AC:41W
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440×230×43.6 mm
Weight : ≤ 3.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-52S-LI-GL] H3C S5130S-52S-LI

H3C S5130S-52S-LI L2 Ethernet Switch
48*10/100/1000Base-T Ports
4*1G/10G Base-X SFP Plus Ports, (AC)
Port switching capacity : 176Gbps
Packet forwarding rate : 132Mpps
Input voltage range : 100 VAC to 240 VAC @ 50 Hz/60 Hz
Power consumption : MIN AC: 19W, MAX AC: 44W
Console ports : 1
VLAN : Port-based, QinQ, MAC, Voice
Dimensions (W × D x H) : 43.6 × 440 × 230 mm
Weight : <3.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-28S-PWR-EI-GL] H3C S5130S-28S-PWR-EI

H3C S5130S-28S-PWR-EI-GL L2 Ethernet Switch
24*10/100/1000BASE-T PoE+ Ports (AC 185W)
4*1G/10G BASE-X SFP Plus Ports, (AC)
Switching capacity : 128Gbps
Forwarding Capacity : 96Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC: 20W, MAX: AC: 235W (PoE 170W)
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440×260×43.6 mm
Weight : ≤ 4kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-28PS-EI-GL] H3C S5130S-28PS-EI

H3C S5130S-28PS-EI-GL L2 Ethernet Switch
24*10/100/1000BASE-T Ports
8*SFP Combo Ports
4*10G BASEX SFP+ Ports, (AC/DC)
Switching capacity : 128Gbps
Forwarding Capacity : 96Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC: 14.5W DC: 14W, MAX: AC: 33W DC: 32W
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz DC: Rated voltage range -54V～-57V DC
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440*360*43.6 mm
Weight : ≤ 5.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[EWP-WA6628X-FIT] H3C Outdoor WA6628X

H3C WA6628X-FIT External Antennas
12 Streams Dual Radio 802.11ax/ac/n Industrial Access Point, FIT
Fixed port
- 1×100M/1000M Ethernet port, support IoT Expansion & PSE, 802.3af
- 2xSFP+
- 1×Console port (RJ45)
Power Source : Local Power Supply (100-264V AC)
Power consumption : ≤52W (Including PSE)
Protection degree : IP67
Dimensions (H×W×D) : 280mm×280mm×85mm
Weight : 3.2 kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-28ST-PWR-EI-GL] H3C S5130S-28ST-PWR-EI

H3C S5130S-28ST-PWR-EI-GL L2 Ethernet Switch
24*10/100/1000Base-T Ports
2*10G BASE-X SFP+ Ports
2*1/2.5/5/10G BASE-T Ports, (PoE+,AC)
Switching capacity : 128Gbps
Forwarding Capacity : 96Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC: 24.5W, MAX:AC: 420W (PoE 370W)
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440*320*43.6 mm
Weight : ≤ 4.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-52TP-EI-GL] H3C S5130S-52TP-EI

H3C S5130S-52TP-EI-GL L2 Ethernet Switch
48*10/100/1000Base-T Ports
2*GE Combo Ports
2*100/1000Base-X SFP Combo Ports
2*1000Base-X SFP Ports, (AC)
Switching capacity : 104Gbps
Forwarding Capacity : 75Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC:20W, MAX: AC:42W
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440×230×43.6 mm
Weight : ≤ 3.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[RT-MSR1004S-5G-GL] H3C MSR1004S-5G

H3C MSR1004S-5G-GL Router
2*GE (SFP), 5*GE (RJ45), 5G NR (NSA/SA, 4G FDD/TDD LTE-A, 3G WCDMA, Sub6, GNSS)
Forwarding Performance : 1 Gbps
Memory : 1 GB
Flash : 512MB
LAN port : 4 × GE copper ports
1 USB 2.0 port
1 Console ports
1 × GE copper port
2 × GE fiber ports
Dimensions (H×W×D) : 52.4 × 150 × 127 mm

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5130S-28S-HPWR-EI-GL] H3C S5130S-28S-HPWR-EI

H3C S5130S-28S-HPWR-EI-GL L2 Ethernet Switch
24*10/100/1000BASE-T PoE+(Including 4*SFP Combo) Ports
4*1G/10GBASE-X SFP Plus Ports, (AC/DC)
Switching capacity : 128Gbps
Forwarding Capacity : 96Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC: 24W DC: 17W, MAX: AC: 451W (PoE 370W) DC:793W (PoE 740W)
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz DC: Rated voltage range -54V～-57V DC
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440×260×43.6 mm
Weight : ≤ 4.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5170-28S-HPWR-EI-GL] H3C S5170-28S-HPWR-EI

H3C S5170-28S-HPWR-EI-GL L2 Ethernet Switch
24*10/100/1000BASE-T Ports
4*1G/10G BASE-X SFP Plus Ports, (AC), POE+
PoE power capacity : 370W
Switching capacity : 128Gbps
Forwarding Capacity : 96Mpps
Flash/SDRAM : 512M/1G
CPU : 1GHz, 2Cores
Latency (64byte/µs) : GE: < 5µs, 10GE < 3µs
Input voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz, Max voltage range: 90V~ 264V AC, 47~63HZ
Power consumption : 460W (including 370w PoE)
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice VLAN/Private VLAN/Super VLAN, GVRP, Dynamic, Hardware-based switching, Guest
Dimensions (W × D x H) : 440mm×320mm×43.6mm
Weight : ≤ 5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-28S-HI-GL] H3C S5130S-28S-HI

H3C S5130S-28S-HI-GL Ethernet Switch
24*10/100/1000BASE-T Ports
8*100/1000BASE-X SFP Combo Ports
4*1G/10G BASE-X SFP Plus Ports, dual power supply slots
Switching capacity : 128Gbps
Forwarding Capacity : 96Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Console port
- 1 × RJ-45 Out of Band console port
- 1 × Micro-USB(Type B) console port
- Only the Micro-USB console port is available when you connect both ports.
Power consumption : Single AC: 34W, Single DC: 36W, Dual AC: 39W, Dual DC: 44W
VLAN : Port-based (up to 4094 VLANs), MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice, GVRP, Tagging, Jumbo frame support
Dimensions (W × D x H) : 440×360×43.6 mm
Weight : ≤ 6kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-6520X-10XT-SI] H3C S6520X-10XT-SI

H3C S6520X-10XT-SI L3 Ethernet Switch
8*1G/2.5G/5G/10GBase-T Ports
2*1G/10GBase-X SFP Plus Ports, (AC)
Switching capacity : 200Gbps
Forwarding Capacity : 240Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, Private, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 260 × 43.6 mm
Weight : ≤ 3.4kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5570S-28S-EI-GL] H3C S5570S-28S-EI

H3C S5570S-28S-EI-GL L3 Ethernet Switch
24*10/100/1000BASE-T Ports
4*1G/10G BASE-X SFP Plus Ports, Without Power Supplies
Switching capacity : 128Gbps
Forwarding Capacity : 96Mpps
Flash/SDRAM : 512M/1G
CPU : 1GHz, 2Cores
Console ports : 1 console port (RJ45)
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice, GVRP
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 5.6kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5560S-28S-PWR-EI-GL] H3C S5560S-28S-PWR-EI

H3C S5560S-28S-PWR-EI-GL L3 Ethernet Switch
24*10/100/1000BASE-T Ports
4*100/1000BASE-X SFP Combo Ports
4*1G/10G BASE-X SFP Plus Ports
Switching capacity : 128Gbps
Forwarding Capacity : 96 Mpps
Flash/SDRAM : 512MB/512MB
CPU : 1 Core, 800MHz
Input voltage : AC: 100 VAC to 240 VAC @ 50 Hz/60 Hz, DC: –36 VDC to –72 VDC
Console ports :
- 1 × RJ-45 console port
- 1 × Micro-USB port
- Only the Micro-USB port is available if you connect both ports
VLAN : Port-based, MAC-based, Protocol-based, IP subnet based, QinQ and selective QinQ, Mapping, Voice, MVRP
Dimensions (W × D x H) : 43.6 × 440 × 460 mm
Weight : ≤ 8.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5570S-28S-HPWR-EI-A-GL] H3C S5570S-28S-HPWR-EI-A

H3C S5570S-28S-HPWR-EI-A-GL L3 Ethernet Switch
24*10/100/1000BASE-T Ports
4*1G/10G BASE-X SFP Plus Ports, Without Power Supplies, POE+
Switching capacity : 128Gbps
Forwarding Capacity : 96Mpps
Flash/SDRAM : 512M/1G
CPU : 1GHz, 2Cores
Console ports : 1 console port (RJ45)
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice, GVRP
Dimensions (W × D x H) : 440×400×43.6 mm
Weight : ≤ 7.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-28S-PWR-HI-GL] H3C S5130S-28S-PWR-HI

H3C S5130S-28S-PWR-HI-GL Ethernet Switch
24*10/100/1000BASE-T PoE+ Ports
4*100/1000BASE-X SFP Combo Ports
4*1G/10G BASE-X SFP Plus Ports, dual power supply slots
Switching capacity : 128Gbps
Forwarding Capacity : 96Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Console port
- 1 × RJ-45 Out of Band console port
- 1 × Micro-USB(Type B) console port
- Only the Micro-USB console port is available when you connect both ports
Power consumption : Single AC: Upto 898W (including 810W PoE), Dual AC : Upto 905W (including 810W PoE)
VLAN : Port-based (up to 4094 VLANs), MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice, GVRP, Tagging, Jumbo frame support
Dimensions (W × D x H) : 440×460×43.6 mm
Weight : ≤ 8.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-28C-HI-GL] H3C S5130S-28C-HI

H3C S5130S-28C-HI-GL L2 Ethernet Switch
24*10/100/1000BASE-T Ports
8*SFP Combo Ports
4*10G BASE-X SFP Plus Ports
1*Slot, dual power supplyslots
Switching capacity : 128Gbps
Forwarding Capacity : 96Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Console port
- 1 × RJ-45 Out of Band console port
- 1 × Micro-USB(Type B) console port
- Only the Micro-USB console port is available when you connect both ports
Power consumption : Single AC: 30W, Single DC: 32W, Dual AC: 38W, Dual DC: 38W
VLAN : Port-based (up to 4094 VLANs), MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice, GVRP, Tagging, Jumbo frame support
Dimensions (W × D x H) : 440×360×43.6 mm
Weight : ≤ 4.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-52S-EI-GL] H3C S5130S-52S-EI

H3C S5130S-52S-EI-GL L2 Ethernet Switch
48*10/100/1000BASE-T Ports
4*1G/10G BASE-X SFP Plus Ports, (AC)
Switching capacity : 176Gbps
Forwarding Capacity : 131Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC:19W, MAX: AC:44W
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440×230×43.6 mm
Weight : ≤ 3.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-52ST-EI-GL] H3C S5130S-52ST-EI

H3C S5130S-52ST-EI-GL L2 Ethernet Switch
48*10/100/1000Base-T Ports
2*10G BASE-X SFP+ Ports
2*1/2.5/5/10G BASE-T Ports, (AC)
Switching capacity : 176Gbps
Forwarding Capacity : 132Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC:24.5W, MAX: AC:43W
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440×260×43.6 mm
Weight : ≤ 3.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-28C-PWR-HI-GL] H3C S5130S-28C-PWR-HI

H3C S5130S-28C-PWR-HI-GL L2 Ethernet Switch
24*10/100/1000BASE-T(PoE+) Ports
4*SFP Combo Ports
4*10G BASE-X SFP Plus Ports
1*Slot, dual power supply slots
Switching capacity : 128Gbps
Forwarding Capacity : 96Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Console port
- 1 × RJ-45 Out of Band console port
- 1 × Micro-USB(Type B) console port
- Only the Micro-USB console port is available when you connect both ports
Power consumption : Single AC: Upto 907W (including 810W PoE), Dual AC : Upto 918W (including 810W PoE)
VLAN : Port-based (up to 4094 VLANs), MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice, GVRP, Tagging, Jumbo frame support
Dimensions (W × D x H) : 440×460×43.6 mm
Weight : ≤ 5.4kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5570S-36F-EI-GL] H3C S5570S-36F-EI

H3C S5570S-36F-EI-GL L3 Ethernet Switch
24*1000BASE-X SFP Ports
8*10/100/1000BASE-T Ports
4*1G/10G BASE-X SFP Plus Ports, Without Power Supplies
Switching capacity : 144Gbps
Forwarding Capacity : 108Mpps
Flash/SDRAM : 512M/1G
CPU : 1GHz, 2Cores
Console ports : 1 console port (RJ45)
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice, GVRP
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 4.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[EWP-WA6630X-FIT] H3C Outdoor WA6630X

H3C WA6630X-FIT Internal Antennas
10 Streams Triple Radio 802.11ax/ac/n Access Point, FIT
Fixed port
- 1×100M/1000M/2.5G/5G/10G Ethernet multi-rate ports
- 2×100M/1000M Ethernet port, GE*2 support IoT extension, PSE:802.3af
- 1×Console port (RJ45)
Power Source
- PoE Injector+55V DC Adapter (Required)
- Adapted to 47~57V DC
Power consumption
- ≤48.6W (include PoE_OUT）
- ≤33.6W (exclude PoE_OUT)
Protection degree : IP68
Dimensions (H×W×D) : 260mm x 260mm x 394mm
Weight : 4.0 kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5170-54S-EI-GL] H3C S5170-54S-EI

H3C S5170-54S-EI-GL L2 Ethernet Switch
48*10/100/1000BASE-T Ports
6*1G/10G BASEX SFP Plus Ports, (AC)
Switching capacity : 216Gbps
Forwarding Capacity : 161Mpps
Flash/SDRAM : 512M/1G
CPU : 1GHz, 2Cores
Latency (64byte/µs) : GE: < 5µs, 10GE < 3µs
Input voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz, Max voltage range: 90V~ 264V AC, 47~63HZ
Power consumption : 53W
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice VLAN/Private VLAN/Super VLAN, GVRP, Dynamic, Hardware-based switching, Guest
Dimensions (W × D x H) : 440mm×260mm ×43.6mm
Weight : ≤ 4kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-52F-EI-GL] H3C S5130S-52F-EI

H3C S5130S-52F-EI-GL L2 Ethernet Switch
48*100/1000 BASE-X SFP Ports
2*GE Combo Ports
4*1G/10G BASE-X SFP Plus Ports, Without Power Supplies
Switching capacity : 176Gbps
Forwarding Capacity : 131Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption
- MIN: Single PSR75-12A: 45 W, Dual PSR75-12A: 48 W, Single PSR150-A1: 48 W, Single PSR150-D1: 51 W, Dual PSR150-A1: 55 W, Dual PSR150-D1: 57 W
- MAX: Single PSR75-12A: 69 W, Dual PSR75-12A: 72 W, Single PSR150-A1: 74 W, Single PSR150-D1: 84 W, Dual PSR150-A1: 95 W, Dual PSR150-D1: 95 W
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage
- AC: Rated voltage range: 100V~240V AC, 50/60Hz
- DC: Rated voltage range -54V～-57V DC
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440×360×43.6 mm
Weight : ≤ 6.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-6520X-18C-SI-GL] H3C S6520X-18C-SI

H3C S6520X-18C-SI-GL L3 Ethernet Switch
16*1G/10G BASE-X SFP Plus Ports
1*Slot, Without Power Supplies
Switching capacity : 480Gbps
Forwarding Capacity : 357Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, Private, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 4.1kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6520X-16ST-SI-GL] H3C S6520X-16ST-SI

H3C S6520X-16ST-SI-GL L3 Ethernet Switch
16*1G/10G BASE-X SFP Plus Ports (2XG Combo), Without Power Supplies
Switching capacity : 320Gbps
Forwarding Capacity : 240Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, Private, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 3.9kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6520X-16XT-SI] H3C S6520X-16XT-SI

H3C S6520X-16XT-SI L3 Ethernet Switch
14*1G/2.5G/5G/10GBase-T Ports
2*1G/10GBase-X SFP Plus Ports, (AC)
Switching capacity : 320Gbps
Forwarding Capacity : 240Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, Private, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 260 × 43.6 mm
Weight : ≤ 3.4kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5130S-52ST-PWR-EI-GL] H3C S5130S-52ST-PWR-EI

H3C S5130S-52ST-PWR-EI-GL L2 Ethernet Switch
48*10/100/1000Base-T Ports
2*10G BASE-X SFP+ Ports
2*1/2.5/5/10G BASE-T Ports,(PoE+, AC)
Switching capacity : 176Gbps
Forwarding Capacity : 132Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Power consumption : MIN: AC: 34.5W, MAX: AC: 430W (PoE 370W)
Latency (64byte/µs) : GE: < 5µs 10GE < 3µs
Input Voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, VLAN mapping, Voice VLAN, GVRP
Dimensions (W × D x H) : 440×320×43.6 mm
Weight : ≤ 6kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-52S-HI-GL] H3C S5130S-52S-HI

H3C S5130S-52S-HI-GL Ethernet Switch
48*10/100/1000BASE-T Ports
4*1G/10GBASE-X SFP Plus Ports, dual power supply slots
Switching capacity : 176Gbps
Forwarding Capacity : 132Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Console port
- 1 × RJ-45 Out of Band console port
- 1 × Micro-USB(Type B) console port
- Only the Micro-USB console port is available when you connect both ports
Power consumption : Single AC: 52W, Single DC: 53W, Dual AC: 55W, Dual DC: 57W
VLAN : Port-based (up to 4094 VLANs), MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice, GVRP, Tagging, Jumbo frame support
Dimensions (W × D x H) : 440×360×43.6 mm
Weight : ≤ 6.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[EWP-WX2880X] H3C Controller WX2880X

H3C WX2880X Access Controller
10*1000BASE-T Ports
2*SFP Plus Ports
Wireless throughput : 10Gbps
Port
- WAN 2 x 2.5GE
- LAN 8 x GE
- LAN 2 x SFP+
- 1 x USB
- 1 x Console
Power supplies : Built in dual power supply
MTBF : ≥145 yrs
Dimensions (WxDxH) : 440 mm *250 mm *43.6 mm
Weight : 3.3 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5170-54S-PWR-EI-GL] H3C S5170-54S-PWR-EI

H3C S5170-54S-PWR-EI-GL L2 Ethernet Switch
48*10/100/1000BASE-T Ports
6*1G/10G BASE-X SFP Plus Ports, (AC), POE+
PoE power capacity : 370W
Switching capacity : 216Gbps
Forwarding Capacity : 161Mpps
Flash/SDRAM : 512M/1G
CPU : 1GHz, 2Cores
Latency (64byte/µs) : GE: < 5µs, 10GE < 3µs
Input voltage : AC: Rated voltage range: 100V~240V AC, 50/60Hz, Max voltage range: 90V~ 264V AC, 47~63HZ
Power consumption : 470W (including 370w PoE)
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice VLAN/Private VLAN/Super VLAN, GVRP, Dynamic, Hardware-based switching, Guest
Dimensions (W × D x H) : 440mm×320mm×43.6mm
Weight : ≤ 5.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5570S-54S-EI-GL] H3C S5570S-54S-EI

H3C S5570S-54S-EI-GL L3 Ethernet Switch
48*10/100/1000BASE-T Ports
6*1G/10G BASE-X SFP Plus Ports, Without Power Supplies
Switching capacity : 216Gbps
Forwarding Capacity : 161Mpps
Flash/SDRAM : 512M/1G
CPU : 1GHz, 2Cores
Console ports : 1 console port (RJ45)
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice, GVRP
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 6kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-6520X-26C-SI-GL] H3C S6520X-26C-SI

H3C S6520X-26C-SI-GL L3 Ethernet Switch
24*1G/10G BASE-X SFP Plus Ports
1*Slot, Without Power Supplies
Switching capacity : 720Gbps
Forwarding Capacity : 536Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, Private, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 4.2kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6520X-24ST-SI-GL] H3C S6520X-24ST-SI

H3C S6520X-24ST-SI-GL L3 Ethernet Switch
24*1G/10G BASE-X SFP Plus Ports (2XG Combo), Without Power Supplies
Switching capacity : 480Gbps
Forwarding Capacity : 357Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, Private, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 4kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5560X-30C-EI-GL] H3C S5560X-30C-EI

H3C S5560X-30C-EI-GL L3 Ethernet Switch
24GE (8SFP Combo)
4SFP Plus+1Slot, Without Power Supplies
Switching capacity : 288Gbps
Forwarding Capacity : 216 Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual Core, 800MHz
Console ports :
- 1×RJ-45 console port
- 1×Micro-USB console port
- Only the Micro-USB console port is available when you connect both ports.
VLAN : Port-based, MAC-based, Protocol-based, IP subnet based, Dynamic, QinQ and selective QinQ, Mapping, Voice, MVRP (GVRP analog), Hardware-based switching
Dimensions (W × D x H) : 43.6 × 440 × 360 mm
Weight : ≤ 6.7kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-6520X-26MC-SI-GL] H3C S6520X-26MC-SI

H3C S6520X-26MC-SI-GL L3 Ethernet Switch
24*100M/1G/2.5G/5GBase-T Ports
1*Slot, Without Power Supplies
Switching capacity : 400Gbps
Forwarding Capacity : 240Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, Private, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 6.4 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5570S-54S-PWR-EI-A-GL] H3C S5570S-54S-PWR-EI-A

H3C S5570S-54S-PWR-EI-A-GL L3 Ethernet Switch
48*10/100/1000BASE-T Ports
6*1G/10G BASE-X SFP Plus Ports, Without Power Supplies, POE+
Switching capacity : 216Gbps
Forwarding Capacity : 161Mpps
Flash/SDRAM : 512M/1G
CPU : 1GHz, 2Cores
Console ports : 1 console port (RJ45)
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice, GVRP
Dimensions (W × D x H) : 440 × 440 × 43.6 mm
Weight : ≤ 7.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5130S-52S-PWR-HI-GL] H3C S5130S-52S-PWR-HI

H3C S5130S-52S-PWR-HI-GL Ethernet Switch
48*10/100/1000BASE-T PoE+ Ports
4*1G/10G BASE-X SFP Plus Ports, dual power supply slots
Switching capacity : 176Gbps
Forwarding Capacity : 132Mpps
CPU : 1 Core, 800MHz
Flash/SDRAM : 256MB/512MB
Console port
- 1 × RJ-45 Out of Band console port
- 1 × Micro-USB(Type B) console port
- Only the Micro-USB console port is available when you connect both ports
Power consumption : Single AC: Upto 1019W (including 900W PoE), Dual AC: Upto 1854W (including 1680W PoE)
VLAN : Port-based (up to 4094 VLANs), MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice, GVRP, Tagging, Jumbo frame support
Dimensions (W × D x H) : 440×460×43.6 mm
Weight : ≤ 9.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5560X-34S-EI-GL] H3C S5560X-34S-EI

H3C S5560X-34S-EI-GL L3 Ethernet Switch
28GE (4SFP Combo)
4SFP Plus+2QSFP Plus, AC/DC
Switching capacity : 288Gbps
Forwarding Capacity : 216 Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual Core, 800MHz
Console ports :
- 1×RJ-45 console port
- 1×Micro-USB console port
- Only the Micro-USB console port is available when you connect both ports.
VLAN : Port-based, MAC-based, Protocol-based, IP subnet based, Dynamic, QinQ and selective QinQ, Mapping, Voice, MVRP (GVRP analog), Hardware-based switching
Dimensions (W × D x H) : 43.6 ×440 × 260 mm
Weight : ≤ 3.6kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5560X-30C-PWR-EI-GL] H3C S5560X-30C-PWR-EI

H3C S5560X-30C-PWR-EI-GL L3 Ethernet Switch
24*10/100/1000BASE-T Ports
4*10G/1G BASE-X SFP+ Ports
1*Slot, PoE, Without Power Supplies
Switching capacity : 288Gbps
Forwarding Capacity : 216 Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual Core, 800MHz
Console ports :
- 1×RJ-45 console port
- 1×Micro-USB console port
- Only the Micro-USB console port is available when you connect both ports.
VLAN : Port-based, MAC-based, Protocol-based, IP subnet based, Dynamic, QinQ and selective QinQ, Mapping, Voice, MVRP (GVRP analog), Hardware-based switching
Dimensions (W × D x H) : 43.6 ×440 × 460 mm
Weight : ≤ 9.2kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5570S-54F-EI-GL] H3C S5570S-54F-EI

H3C S5570S-54F-EI-GL L3 Ethernet Switch
48*1000BASE-X SFP Ports
6*1G/10G BASE-X SFP Plus Ports, Without Power Supplies
Switching capacity : 216Gbps
Forwarding Capacity : 161Mpps
Flash/SDRAM : 512M/1G
CPU : 1GHz, 2Cores
Console ports : 1 console port (RJ45)
VLAN : Port-based, MAC-based, Protocol-based, QinQ and selective QinQ, Mapping, Voice, GVRP
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 4.5kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-6520X-26MC-UPWR-SI-GL] H3C S6520X-26MC-UPWR-SI

H3C S6520X-26MC-UPWR-SI-GL L3 Ethernet Switch
24*100M/1G/2.5G/5GBaseT (UPOE) Ports
1*Slot, Without Power Supplies
Switching capacity : 400Gbps
Forwarding Capacity : 240Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, Private, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 460 × 43.6 mm
Weight : ≤ 8.7 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5560X-30F-EI-GL] H3C S5560X-30F-EI

H3C S5560X-30F-EI-GL L3 Ethernet Switch
24SFP (8GE Combo)
4SFP Plus+1Slot, Without Power Supplies
Switching capacity : 288Gbps
Forwarding Capacity : 216 Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual Core, 800MHz
Console ports :
- 1×RJ-45 console port
- 1×Micro-USB console port
- Only the Micro-USB console port is available when you connect both ports.
VLAN : Port-based, MAC-based, Protocol-based, IP subnet based, Dynamic, QinQ and selective QinQ, Mapping, Voice, MVRP (GVRP analog), Hardware-based switching
Dimensions (W × D x H) : 43.6 ×440 × 360 mm
Weight : ≤ 6.6kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5560X-54S-EI-GL] H3C S5560X-54S-EI

H3C S5560X-54S-EI-GL L3 Ethernet Switch
48*10/100/1000BASE-T Ports
4*10G/1G BASE-X SFP+ Ports
2*40G QSFP+ Ports, AC/DC
Switching capacity : 336Gbps
Forwarding Capacity : 252 Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual Core, 800MHz
Console ports :
- 1×RJ-45 console port
- 1×Micro-USB console port
- Only the Micro-USB console port is available when you connect both ports.
VLAN : Port-based, MAC-based, Protocol-based, IP subnet based, Dynamic, QinQ and selective QinQ, Mapping, Voice, MVRP (GVRP analog), Hardware-based switching
Dimensions (W × D x H) : 43.6 × 440 × 260 mm
Weight : ≤ 3.9kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5560X-30F-EIF-GL] H3C S5560X-30F-EIF

H3C S5560X-30F-EIF-GL L3 Ethernet Switch
24SFP+4SFP Plus+2QSFP Plus, AC/DC
Switching capacity : 288Gbps
Forwarding Capacity : 216 Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual Core, 800MHz
Console ports :
- 1×RJ-45 console port
- 1×Micro-USB console port
- Only the Micro-USB console port is available when you connect both ports.
VLAN : Port-based, MAC-based, Protocol-based, IP subnet based, Dynamic, QinQ and selective QinQ, Mapping, Voice, MVRP (GVRP analog), Hardware-based switching
Dimensions (W × D x H) : 43.6 ×440 × 220 mm
Weight : ≤ 3.2kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5560X-54C-EI-GL] H3C S5560X-54C-EI

H3C S5560X-54C-EI-GL L3 Ethernet Switch
48*10/100/1000BASE-T Ports
4*10G/1G BASE-X SFP+ Ports
1*Slot, Without Power Supplies
Switching capacity : 336Gbps
Forwarding Capacity : 252 Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual Core, 800MHz
Console ports :
- 1×RJ-45 console port
- 1×Micro-USB console port
- Only the Micro-USB console port is available when you connect both ports.
VLAN : Port-based, MAC-based, Protocol-based, IP subnet based, Dynamic, QinQ and selective QinQ, Mapping, Voice, MVRP (GVRP analog), Hardware-based switching
Dimensions (W × D x H) : 43.6 ×440 × 360 mm
Weight : ≤ 7kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-5560X-54C-PWR-EI-GL] H3C S5560X-54C-PWR-EI

H3C S5560X-54C-PWR-EI-GL L3 Ethernet Switch
48*10/100/1000BASE-T Ports
4*10G/1G BASE-X SFP+ Ports
1*Slot, PoE, Without Power Supplies
Switching capacity : 336Gbps
Forwarding Capacity : 252 Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual Core, 800MHz
Console ports :
- 1×RJ-45 console port
- 1×Micro-USB console port
- Only the Micro-USB console port is available when you connect both ports.
VLAN : Port-based, MAC-based, Protocol-based, IP subnet based, Dynamic, QinQ and selective QinQ, Mapping, Voice, MVRP (GVRP analog), Hardware-based switching
Dimensions (W × D x H) : 43.6 × 440 × 460 mm
Weight : ≤ 9.6kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-6520X-30QC-EI-GL] H3C S6520X-30QC-EI

H3C S6520X-30QC-EI-GL L3 Ethernet Switch
24SFP Plus + 2QSFP Plus + 2Slot, Without Power Supplies
Switching capacity : 960Gbps
Forwarding Capacity : 705Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+, Dynamic, Hardware-based switching, Voice, Guest
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 7 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6800-2C-H1] H3C S6800-2C

H3C S6800-2C L3 Ethernet Switch
2*QSFP Plus Ports
2*Interface Module Slots
Switching capacity : 1.44Tbps
Forwarding Capacity : 1080Mpps
Flash/SDRAM : 1GB/4GB
CPU : 1GHz@2Core
VLAN : Port-based, Mac-based, Subnet-based and Protocol VLAN, QinQ, Mapping, MVRP, Super VLAN, PVLAN
Dimensions (H × W × D) : 44.2×440×660mm
Weight : ≤ 16 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6520X-26XC-UPWR-SI] H3C S6520X-26XC-UPWR-SI

H3C S6520X-26XC-UPWR-SI L3 Ethernet Switch
24*100M/1G/2.5G/5G/10GBaseT UPoE Ports
1*Slot, Without Power Supplies
Switching capacity : 640Gbps
Forwarding Capacity : 240Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, Private, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 460 × 43.6 mm
Weight : ≤ 8.8 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-5560X-54F-EI-GL] H3C S5560X-54F-EI

H3C S5560X-54F-EI-GL L3 Ethernet Switch
48*100/1000 Base-X SFP Ports
4*10G/1G BASE-X SFP+ Ports
1*Slot, Without Power Supplies
Switching capacity : 336Gbps
Forwarding Capacity : 252 Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual Core, 800MHz
Console ports :
- 1×RJ-45 console port
- 1×Micro-USB console port
- Only the Micro-USB console port is available when you connect both ports.
VLAN : Port-based, MAC-based, Protocol-based, IP subnet based, Dynamic, QinQ and selective QinQ, Mapping, Voice, MVRP (GVRP analog), Hardware-based switching
Dimensions (W × D x H) : 43.6 × 440 × 360 mm
Weight : ≤ 6.7kg

5 Years Warranty Basic 9x5 10BD-Ship Service

[LS-6520X-30QC-HI-GL] H3C S6520X-30QC-HI

H3C S6520X-30QC-HI-GL L3 Ethernet Switch
24SFP Plus+2QSFP Plus+2Slot, Without Power Supplies
Switching capacity : 960Gbps
Forwarding Capacity : 705Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based, Default, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 7 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6800-4C-H1] H3C S6800-4C

H3C S6800-4C L3 Ethernet Switch
4*Interface Module Slots
Switching capacity : 2.56Tbps
Forwarding Capacity : 1440Mpps
Flash/SDRAM : 1GB/4GB
CPU : 1GHz@2Core
VLAN : Port-based, Mac-based, Subnet-based and Protocol VLAN, QinQ, Mapping, MVRP, Super VLAN, PVLAN
Dimensions (H × W × D) : 88.1×440×660mm
Weight : ≤ 27Kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[EWP-WX3820X] H3C Controller WX3820X

H3C WX3820X Access Controller
Throughput : 20Gbps
Port Fixed
- 8 × GE ports
- 8 × SFP ports
- 1 × OOBM port
- 2 × USB ports
Additional ports can be extended through service card
- 8 × GE ports
- 2 × SFP+ ports
Power supplies : Pluggable power supply, 1+1 redundant backup, supporting AC or DC (power supply needs to be configured separately)
Storage : WCG300 1.92TB 6G SATA 2.5in SSD (optional)
Max power consumption : 36 to 107 W
MTBF : ≥83.02 yrs
Dimensions (WxDxH) : 440 mm × 435 mm × 44 mm
Weight : 9 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6520X-30HC-EI-GL] H3C S6520X-30HC-EI

H3C S6520X-30HC-EI-GL L3 Ethernet Switch
24SFP Plus + 2QSFP28 + 2Slot, Without Power Supplies
Switching capacity : 1680Gbps
Forwarding Capacity : 705Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+, Dynamic, Hardware-based switching, Voice, Guest
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 7.4 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6520X-54QC-EI-GL] H3C S6520X-54QC-EI

H3C S6520X-54QC-EI-GL L3 Ethernet Switch
48SFP Plus + 2QSFP Plus + 2Slot, Without Power Supplies
Switching capacity : 1440Gbps
Forwarding Capacity : 1050Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+, Dynamic, Hardware-based switching, Voice, Guest
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 7.2 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6520X-30HC-HI-GL] H3C S6520X-30HC-HI

H3C S6520X-30HC-HI-GL L3 Ethernet Switch
24SFP Plus+2QSFP28+2Slot, Without Power Supplies
Switching capacity : 1680Gbps
Forwarding Capacity : 705Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based, Default, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 7.4 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6520X-54QC-HI-GL] H3C S6520X-54QC-HI

H3C S6520X-54QC-HI-GL L3 Ethernet Switch
48SFP Plus + 2QSFP Plus + 2Slot, Without Power Supplies
Switching capacity : 1440Gbps
Forwarding Capacity : 1050Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based, Default, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 7.2 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6520X-30HF-HI] H3C S6520X-30HF-HI

H3C S6520X-30HF-HI L3 Ethernet Switch
24 SFP Plus Ports
6 QSFP28 Ports, Without Power Supplies
Switching capacity : 1680Gbps
Forwarding Capacity : 705Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based, Default, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 6 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6520X-54HF-EI] H3C S6520X-54HF-EI

H3C S6520X-54HF-EI L3 Ethernet Switch
48*SFP Plus Ports
6*QSFP28 Ports, Without Power Supplies
Switching capacity : 2160Gbps
Forwarding Capacity : 600Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+, Dynamic, Hardware-based switching, Voice, Guest
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 6 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6520X-54HC-EI-GL] H3C S6520X-54HC-EI

H3C S6520X-54HC-EI-GL L3 Ethernet Switch
48SFP Plus + 2QSFP28 + 2Slot, Without Power Supplies
Switching capacity : 2160Gbps
Forwarding Capacity : 1050Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+, Dynamic, Hardware-based switching, Voice, Guest
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 7.6 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6520X-54XC-UPWR-SI] H3C S6520X-54XC-UPWR-SI

H3C S6520X-54XC-UPWR-SI L3 Ethernet Switch
48*100M/1G/2.5G/5G/10GBaseT UPoE Ports
4*QSFP Plus Ports
1*Slot, Without Power Supplies
Switching capacity : 1440Gbps
Forwarding Capacity : 600Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based (up to 4094 VLANs), Default, Private, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 460 × 43.6 mm
Weight : ≤ 10 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6800-54QF-H3] H3C S6800-54QF

H3C S6800-54QF L3 Ethernet Switch
48 SFP Plus Ports
6 QSFP Plus Ports, No Power
Switching capacity : 1.44Tbps
Forwarding Capacity : 1080Mpps
Flash/SDRAM : 1GB/4GB
CPU : 1GHz@2Core
VLAN : Port-based, Mac-based, Subnet-based and Protocol VLAN, QinQ, Mapping, MVRP, Super VLAN, PVLAN
Dimensions (H × W × D) : 44×440×400mm
Weight : ≤ 13kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6520X-54HF-HI] H3C S6520X-54HF-HI

H3C S6520X-54HF-HI L3 Ethernet Switch
48 SFP Plus Ports
6 QSFP28 Ports, Without Power Supplies
Switching capacity : 2160Gbps
Forwarding Capacity : 1050Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based, Default, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 6.5 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6520X-54HC-HI-GL] H3C S6520X-54HC-HI

H3C S6520X-54HC-HI-GL L3 Ethernet Switch
48SFP Plus + 2QSFP28 + 2Slot, Without Power Supplies
Switching capacity : 2160Gbps
Forwarding Capacity : 1050Mpps
Flash/SDRAM : 1GB/2GB
CPU : Dual-Core, 1.6GHz
VLAN : Port-based, Default, QinQ and flexible QinQ, Mapping, PVST+ and RPVST+
Dimensions (W × D x H) : 440 × 360 × 43.6 mm
Weight : ≤ 7.6 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6800-54QT-H3] H3C S6800-54QT

H3C S6800-54QT L3 Ethernet Switch
48 10GBASE-T
6 QSFP Plus Ports
Switching capacity : 1.44Tbps
Forwarding Capacity : 1080Mpps
Flash/SDRAM : 1GB/4GB
CPU : 1GHz@2Core
VLAN : Port-based, Mac-based, Subnet-based and Protocol VLAN, QinQ, Mapping, MVRP, Super VLAN, PVLAN
Dimensions (H × W × D) : 44×440×460mm
Weight : ≤ 13kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[LS-6800-32Q-H1] H3C S6800-32Q

H3C S6800-32Q L3 Ethernet Switch
32 QSFP+ Ports
Switching capacity : 2.56Tbps
Forwarding Capacity : 1440Mpps
Flash/SDRAM : 1GB/4GB
CPU : 1GHz@2Core
VLAN : Port-based, Mac-based, Subnet-based and Protocol VLAN, QinQ, Mapping, MVRP, Super VLAN, PVLAN
Dimensions (H × W × D) : 43.6×440×660mm
Weight : ≤ 13kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[EWP-WX3840X] H3C Controller WX3840X

H3C WX3840X Access Controller
Throughput : 40Gbps
Port Fixed
- 8 × GE ports
- 8 × SFP ports
- 1 × OOBM port
- 2 × USB ports
Expandable to
Additional ports can be extended through service card
- 8 × GE ports
- 4 × SFP+ ports
Power supplies : Pluggable power supply, 1+1 redundant backup, supporting AC or DC (power supply needs to be configured separately)
Storage : WCG300 1.92TB 6G SATA 2.5in SSD (optional)
Max power consumption : 36 to 107 W
MTBF : ≥83.02 yrs
Dimensions (WxDxH) : 440 mm × 435 mm × 44 mm
Weight : 9 kg

1 Year Warranty Basic 9x5 NBD-Ship Service

[EWP-WX5860X] H3C Controller WX5860X

H3C WX5860X Access Controller
Throughput : 80/160Gbps
Ports
Support 2 interface cards at most. The specification of each card
2 x 40G (QSFP+）
8 x 10G (SFP+）
8 x GE Combo
(2×40G and 8×10G are mutuallyexclusive)
1 x Console
2 x USB
1 x OOBM
Power supplies
- Removable AC or DC power modules
- Support for 1+1 or 1+3 power module redundancy (Power module should be purchased separately.)
Max power consumption : < 502 W
MTBF : ≥ 52.4yrs
Dimensions (H × W × D) : 88.1 × 440 × 660 mm
Weight : 22.9 kg

1 Year Warranty Basic 9x5 NBD-Ship Service
